Affordable Multispectral Spectrofluorometer
An open-source instrument in development for comparing fluorescence emission from quantum dots, fluorescent dyes, and other samples without relying on a conventional laboratory fluorometer.
- Primary field
- Materials science, chemistry, and optics
- Measurement
- Relative multispectral fluorescence emission
- Intended users
- Students, educators, and early-stage researchers
- Release state
- Prototype architecture in development
Overview
Lowering the barrier to fluorescence measurement
The Affordable Multispectral Spectrofluorometer is Koinos Lab's flagship instrument project. It explores how much useful fluorescence-measurement capability can be reproduced using accessible optical components, open-source electronics, and a light-controlled enclosure.
The first application is the comparison of fluorescence emission from CdSe quantum-dot samples. The broader goal is an educational platform for investigating emission wavelength, fluorescent dyes, nanomaterials, and optical spectroscopy.
This page documents the intended architecture and release standard. Final dimensions, component models, files, performance limits, and cost will be published only after prototype validation.
Purpose / What it does
Measure meaningful differences in fluorescence emission
The instrument is intended to excite a sample with controlled ultraviolet light, isolate emitted fluorescence from excitation light, and record relative intensity across multiple optical bands. The resulting profile can support comparisons among samples without claiming the full resolution of a research-grade scanning spectrofluorometer.
- Compare relative emission profiles from multiple fluorescent samples.
- Investigate how quantum-dot size relates to observed emission characteristics.
- Introduce excitation, emission, filtering, calibration, and measurement uncertainty.
- Provide a reproducible platform for classroom and independent laboratory activities.
How it works
From controlled excitation to a digital emission profile
-
01
Excite
A controlled UV source illuminates the sample inside a light-restricted enclosure.
-
02
Separate
Optical geometry and filtering reduce direct excitation light reaching the detector.
-
03
Detect
A multispectral optical sensor samples relative intensity across available wavelength bands.
-
04
Process
A microcontroller applies dark-reference and calibration corrections to the raw readings.
-
05
Report
Measurements are displayed locally and prepared for export to analysis software.
Specifications
Target system architecture
| Parameter | Current target | Release status |
|---|---|---|
| Excitation | Controlled ultraviolet LED source | Component selection pending |
| Detection | Multispectral optical sensor | Architecture selected |
| Optical isolation | Filtered, enclosed measurement path | Prototype testing required |
| Sample interface | Repeatable removable sample holder | Mechanical design pending |
| Data acquisition | Microcontroller-based acquisition and local processing | Firmware in development |
| Output | Local display and digital data export | Interface definition pending |
| Enclosure | 3D-printed, light-controlled optical enclosure | CAD in development |
Components / Bill of Materials
Subsystem-level BOM
Exact manufacturer part numbers, quantities, alternatives, suppliers, and verified cost will be released after the prototype design is frozen.
| Subsystem | Required elements | Status |
|---|---|---|
| Excitation | UV LED, driver, thermal management, optical mount | Selection in progress |
| Detection | Multispectral sensor, optical filter, detector mount | Prototype stage |
| Electronics | Microcontroller, power regulation, controls, display, connectors | Architecture stage |
| Mechanical | Optical enclosure, sample holder, fasteners, light seals | CAD pending |
| Calibration | Dark reference, stable fluorescent references, measurement fixtures | Protocol pending |
Blueprints / CAD
Mechanical source files
Editable CAD for the optical enclosure, sensor mount, excitation module, sample holder, and assembly will be released after the first validated mechanical revision.
STL Files
Fabrication-ready exports
Print-oriented STL exports will include documented orientation, support, material, and tolerance guidance. Files will not be published until fit and light-isolation checks are complete.
Wiring / Electronics
Planned electronic architecture
The electronics connect the excitation source, multispectral detector, microcontroller, local controls, display, and data interface. The released schematic will document voltage domains, connector pinouts, grounding, current limits, and safe LED control.
- Regulated power input with documented protection and polarity.
- Microcontroller interface to the multispectral sensor.
- Current-controlled switching for the UV excitation source.
- Local display, user controls, and data-export connection.
Assembly Instructions
Planned reproducible build sequence
- Fabricate and inspect the enclosure and optical mounts.
- Assemble the regulated power and control electronics.
- Mount the detector, filter, excitation source, and sample interface.
- Complete wiring checks before energizing the UV source.
- Install firmware and verify sensor communication.
- Seal the optical path and run dark-reference tests.
- Complete calibration and validation before sample analysis.
Final step-by-step photographs, tools, tolerances, and acceptance checks will accompany the first released hardware revision.
Code / Firmware
Acquisition, correction, and export
The planned open-source software package will separate instrument control from data analysis.
Firmware
Sensor acquisition, excitation timing, controls, display, and data transfer.
Processing
Dark-reference subtraction, calibration factors, quality checks, and structured export.
Analysis
Visualization, sample comparison, metadata capture, and educational workflows.
Calibration
Calibration before interpretation
Calibration will be designed to make repeated measurements comparable and to reveal the limits of the multispectral detector. The final procedure will identify required references, environmental conditions, acceptance limits, and recalibration intervals.
- Warm up the excitation and detection electronics under controlled conditions.
- Record dark readings with the excitation source disabled.
- Measure stable references using fixed sample geometry and timing.
- Calculate channel corrections and document residual variation.
- Verify the calibration against held-out reference measurements.
Testing & Validation
Evidence required before release
| Test | Question | Current state |
|---|---|---|
| Repeatability | Does the same sample produce consistent readings? | Protocol planned |
| Reproducibility | Do independently assembled units produce comparable results? | Requires multiple builds |
| Linearity | How does response change across a controlled concentration series? | Protocol planned |
| Drift | How stable are readings over time and temperature? | Protocol planned |
| Comparison | How closely do measurements align with a professional reference instrument? | Partner access required |
Experimental Data
Raw data will accompany every performance claim
Validation datasets will be published in machine-readable form with sample identifiers, acquisition settings, calibration version, environmental conditions, exclusions, and analysis scripts.
Results
No validated performance results yet
Koinos Lab will not publish accuracy, precision, detection-limit, wavelength, or cost claims until the prototype has completed the documented validation process. Results will include both useful capabilities and measured limitations.
Safety Notes
UV exposure and sample handling require controls
- Never operate the UV excitation source with the optical enclosure open.
- Use interlocks or equivalent engineering controls in the released design.
- Do not look directly into the excitation source or reflected UV light.
- Follow applicable chemical handling and disposal procedures for every sample.
- CdSe quantum dots may contain toxic cadmium; use only under qualified supervision and an approved safety protocol.
- Verify wiring, polarity, current limits, insulation, and enclosure integrity before operation.
This pre-release page is not a substitute for a completed risk assessment or laboratory safety procedure.
